Material

Tungsten Carbide(YG12),SKD-51,W6Mo5Cr4V2,D2 and so on

Advantage

Burr-free, Widely Applied

Thickness

0.8-1.5mm, Customized thickness available

Inner diameter

25.4, 32, 38mm

Outer diameter

OD160 - 610mm, customized size is available

Knife edge

45 °,could be adjusted according to your requirement

Design

single edge and double edge are available

Appliacation

Paper, film, foam, rubber,foil, graphite and so on

Specification

Outer diameter

Inner diameter

Thickness

Knife edge type

Material

180x25.4x2.0

Φ180

Φ25.4

2.0T

Single side edge

YG12

200x25.4x2.0

Φ200

Φ25.4

2.0T

Double side edge

SKH-51

250x25.4x2.5

Φ250

Φ25.4

2.5T

Sliced edge

W6Mo5Cr4V2

250x25.4x3.0

Φ250

Φ25.4

3.0T

D2

300x25.4x3.0

Φ300

Φ25.4

3.0T

300x25.4x3.5

Φ300

Φ25.4

3.5T

350x25.4x3.5

Φ350
